Description
The 316 Wafer Segment Ball Valve is series Stainless V port Ball Valve is primarily designed for flow control, and it can also be used for shut-off operation. The notched port on the segment ball contributes to strong shear stress to cut through media with fibers and particles. Consequently, this Segment Ball Valve is a good general control valve (equal percentage flow character) for most pulp and paper process applications, or similar flow contains fibers and particles.
Features:
1. Body:
a) Integral body design offers greater rigidity against fluctuating pipe loads.
b) Eliminates the leak path associated with two piece body designs.
c) Both wafer and flange connection are available.
2. Core:
a) Specially designed V-notch ball provides strong cutting stress and tight sealing.
b) Hard chromium, nitriding, and HCOF treatments are all available for the ball surface treatment, improving hardness,
abrasion resistance, fatigue resistance, corrosion resistance and performance under high temperature.
c) Well ground notched ball surface ensures small operating torque and tight seal, especially for metal seated
segment valve.
3. Seat:
a) For valve rated under class 150, retainer is casted on valve body to eliminate any possible space between seat
ring and body for residue accumulation. Consequently, this ensures perfect seal。
b) Specialized spring design decreases valve torque while providing force for tight sealing.
c) Pressure energized seat design offers excellent sealing even at very low differential pressures.
4. Stem:
a) The stem is finely ground to match the actuator excellently, which prevents rocking motion and potential failure
of the segmented valve.
Product Introduction
Product Name | 316 Wafer Segment Ball Valve,PN25,DN50 |
1. Material | 316 |
2. Size | 2” |
4. Port | V Port |
5. Working Pressure | 150lb |
6. Connection Ends | RF |
7. Working Temp. | -29~300ºC, |
8. Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid |
9. Operated | / |
10. Inspection & Testing | According to API598 |
Shipment | |
Delivery Time | 30 Days |
Package | Standard Exporting Plywood Case |
Shipping Port | Ningbo/Shanghai, China |
Shipping Terms | Exw, FOB, CFR, CIF, etc. |
Payment Terms | T/T, Western Union, PayPal, etc. |
30% prepayment, 70% balance paid before shipping | |
Country of Origin | Wenzhou city, China |
Production Capacity | 6000 ton/year |
MOQ | 1 PCS/size |
Size Range: | DN 25~250mm NPS 1”-10” (Wafer)DN 25~500mm NPS 1”-20” (Flange) |
Press. Rate: | PN 10/16/25/40/63ANSI 150/300/600 |
Temp. Range: | Metal Seat -29…+450℃Resilient Seat -29…+150℃ |
Seal Tightness: | Metal Seat Class IVResilient Seat Class VI
|
Body Material: | Carbon Steel, Stainless Steel, Special Alloy |
Ball/Stem Material: | Stainless Steel, Special Alloy |
Seat Material: | Stainless Steel+STL, PCTFE,PEEK (Flange)Stainless Steel+STL (Wafer) |
Face to Face: | ISA S75.04, IEC/DIN 534-3-2 (Flange)Factory Standard (Wafer) |
Flange Standard: | GB/T 9113.1, JB/T 79.1, HG 20592,ASME B 16.34, ISO 7005 (Other drilling on request) |
Appliactions: | Pulp & Paper,Water Treatment,Food & Beverage,Fine Chemical,Power Plant,Steel Industry |
