Description
Product name: DIN 5A Flanged Y Strainer,DN20,PN16,RF END
Design: DIN EN 12516-1
Material: 5A.
Nominal size: 3/4 Inch.
Nominal pressure: PN16.
End Connection: RF.
Face to face: DIN EN558.1.
Test and inspection: DIN N12266.1.
Product Range：
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 – 48 Inch (DN15 – DN1200).
End connection: BW, Flanged.
Pressure range: 150 – 2500 LB (PN16 – PN420).
Working temperature: -196℃ – +573℃.
| Product Name | DIN 5A Flanged Y Strainer,DN20,PN16,RF END |
| 1. Material | 5A |
| 2. Size | 3/4” |
| 4. Port | Full Port |
| 5. Working Pressure | PN16 |
| 6. Connection Ends | RF |
| 7. Working Temp. | -29~200ºC, |
| 8. Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid |
| 9. Operated | / |
| 10. Inspection & Testing | DIN N12266.1 |
| Shipment | |
| Delivery Time | 30 Days |
| Package | Standard Exporting Plywood Case |
| Shipping Port | Ningbo/Shanghai, China |
| Shipping Terms | Exw, FOB, CFR, CIF, etc. |
| Payment Terms | T/T, Western Union, PayPal, etc. |
| 30% prepayment, 70% balance paid before shipping | |
| Country of Origin | Wenzhou city, China |
| Production Capacity | 6000 ton/year |
| MOQ | 1 PCS/size |
