Description
Design and Manufacture：API 6D,ASME B16.34(BS5351),API 608,MSS-SP-72
Face to Face Dimension：ASME B16.10,API 6D
Flange Connection Dimension：ASME B 16.5
BW Connection Dimension：ASME B16.25
Test and Inspection：API 598,API 6D
Fire-Safe Design:API 607/6FA
Anti-Static Design&Anti Blow-Out Stem
Product Range
Body material: carbon steel, stainless steel, alloy steel
Full bore and reduced bore design
Nominal diameter:1/2″~10″（DN15~DN250）
End Connection: RF,RTJ, BW
Pressure range: Class150~600（PN16~PN100）
Working temperature: -46℃~+200℃
Operation : Handle, Gear, Electric actuator, etc
| Product Name | 600LB Cast Steel Ball Valve,2 Inch,RF End |
| 1. Material | WCB |
| 2. Size | 2” |
| 4. Port | Full Port |
| 5. Working Pressure | 600lb |
| 6. Connection Ends | RF |
| 7. Working Temp. | -29~120ºC, |
| 8. Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid |
| 9. Operated | Handwheel |
| 10. Inspection & Testing | According to API598 |
| Shipment | |
| Delivery Time | 30 Days |
| Package | Standard Exporting Plywood Case |
| Shipping Port | Ningbo/Shanghai, China |
| Shipping Terms | Exw, FOB, CFR, CIF, etc. |
| Payment Terms | T/T, Western Union, PayPal, etc. |
| 30% prepayment, 70% balance paid before shipping | |
| Country of Origin | Wenzhou city, China |
| Production Capacity | 6000 ton/year |
| MOQ | 1 PCS/size |
